Product Details:
Payment & Shipping Terms:
|
| Brand Name: | Automatic Swing Wire Fence Mesh Welding Machine | Condition: | New |
|---|---|---|---|
| Color: | Customized | Voltage: | 380v |
| Control: | PLC | Warranty: | One Year |
Automatic Swing Wire Fence Mesh Welding Machine Smooth Mesh Surface , Saving Labor
Description
Welder specifications and diverse, wide range of uses.But for the fence mesh, the welding machine can produce a variety of guardrails such as climbing net also known as dense net, mainly for prisons, military land and so on. Triangle folding fence, double fence, bilateral wire fence and so on, mainly for residential, airports, railways, roads and so on the fence, can also be used for the factory fence, or enclosure with barbed wire and so on.
peculiarity
1. Using servo motor control network pull, improve the accuracy of the grid.
2. Using rack and pinion transmission, transmission efficiency.
3. The grid can vary according to different needs.
4. Splash small, low burn marks, improve the appearance of the net panel.
5. Working speed, work stability, improve productivity.
parameters
| Automatic Swing Wire Fence Mesh Welding Machine | |
| Wire diameter | 2.5-6mm |
| Longitude wire space | 50-300mm |
| Cross wire space | 25-300mm |
| Net width | Max.1200 |
| Rated voltage | 380V/220V/415V/440V,50HZ/60HZ as required |
| Rated power | ≥125KVA*X+motor power |
| Welding speed | 75-85 times/min |
| Weight | 3T |
| The Wire Mesh Welding Machine is also able to be made to order according to customer’s requirement. | |
