Product Details:
Payment & Shipping Terms:
|
| Product Name: | New Type Automatic Fence Steel Wire Mesh Welding Machine | Brand Name: | ChengKe |
|---|---|---|---|
| Usage: | Protective Fence.Construction Fence | Weight: | 4T |
| Warranty: | 1 Year | After-sales: | Overseas Service Provided |
| High Light: | fence panel making machine,diamond mesh fencing machine |
||
New Type Automatic Fence Steel Wire Mesh Welding Machine Easy Operation
description
New automatic welding machine, stable and rapid work, save manpower, simple operation, a person can work, cost-effective
Features
1 simple operation: only one button to complete the operation of a product
2. funnel control: funnel which did not stop when no wire or do not drop until it is normal
3. Welding pause: main motor suspension welding operation, the welding is completed and continue to run to ensure a solid weld
5 gear reducer: to ensure high-load operation
6. Pull the net: CNC pull network, Baoding stability, proof of product size precision.
7. Fault display: mechanical failure. Touch screen will be displayed for easy testing and maintenance
8. Product Size: Product size can be adjusted within the scope of practicality
Specification
| New Type Automatic Fence Steel Wire Mesh Welding Machine Easy Operation | |
| Input power | 380V 50Hz |
| Max. width | 2500mm |
| Line wire space | 50-300mm |
| Cross wire space | ≥25mm |
| Wire diameter | 2.5-6.0mm |
| Rated capacity | 125kva*6 |
| Welding point No. | 48 |
| Motor power | 4.0KW |
| Feed line wire | Pre-cut wire |
| Feed cross wire | Pre-cut wire |
| Welding speed | 30-50 times/min |
| Weight | 4T |
|
Can be customized according to customer requirements. |
|
