Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine

I'm Online Chat Now

Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine

China Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine supplier
Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine supplier Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine supplier Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine supplier Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine supplier

Large Image :  Mild Steel Rebar Mesh Panel Welding Machine , Fully Automatic Welded Wire Mesh Machine

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-RM-2500Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: plastic warps
Delivery Time: 15 Workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 25 Sets/Month
Contact Now
Detailed Product Description
Product Name: Mild Steel Rebar Mesh Welding Machine Welding Width: Max.2.5mm
Wire Diameter: 5-12mm Cross Wire Space: Min.50mm
After-sales: Engineers Available To Service Machinery Overseas Color: Customer's Requirment
High Light:

automatic wire mesh welding machine

,

reinforced mesh welding machine

Mild Steel Rebar Mesh Welding Machine / Reinforcing Construction Mesh Welding Machine


description

1. The welding apertures are adjustable according to you need. What is more,it can change when the machine is working,because it use the PLC and HMI control systemsynchronization CNC technology, welding time and separate welding are controled by PLC digital programInput panel for touch screen or buttons two kinds, which makes the machine more intelligent andrationalization.weldingtransformer,shifting gear can be divided into eight levels, expand the scope of the diameter of the welding wire.It is easy to operate, and the flexibility is high.
.
Features


 It adopts synchronous control skill. The welding time and separate welding are controlled by computer based on Windows operation system, which makes the operation more intelligentized. Mesh drawing system is controlled by servo- motor., which improves the precision of mesh opening size. Meanwhile the longitudinal and transversal spacing are adjustable. It simplifies the process that every tensile spring has to be changed when the welding wire diameter is different. You only need to change the pressure of welding point.



Usage

Construction reinforcing mesh, highway cement concrete pavement using mesh reinforcement , bridge deck pavement using mesh reinforcements, sprayed concrete with mesh reinforcement, tunnel lining with steel mesh

Specification



Mild Steel Rebar Mesh Welding Machine / Reinforcing Construction Mesh Welding Machine
wire diameter 5-12mm
cross wire length Max 2.5m, or 2m or as required
line wire length Max 12m
Aperture 100-300mm
electric capacity 900KVA
welding speed 45-75 times/min
much more details please contact us
