Home ProductsAutomatic Wire Mesh Welding Machine

High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine

I'm Online Chat Now

High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine

China High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine supplier
High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine supplier High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine supplier High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine supplier High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine supplier

Large Image :  High Output Reinforced Mesh Welding Machine , Touch Screen Mesh Panel Welding Machine

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-FM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Automatic Animal Cage Welding Machine Welding Aperture: 50x50-200x200mm
Voltage: 380V Speed: 60 (times/minute)
Warranty: 1 Year After-sales: Overseas Service Provided
High Light:

steel grating welding machine

,

automatic wire mesh machine

Automatic Animal Cage Welding Machine Welding For Breed Aquatic Mesh​





description



1.This machine adopts electrical & electronic control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit.

2.The operation is accurate, it has stable function, firm welded point, without welded tracks.

3.Easy to learn and operate, high speed, low price

4.The machine is equipped with precise equipment for weft cutting positioning, so the length of wefts is identical and regular, it is unnecessary to slice the side.

5. Drawing mesh system adopts elastic tension and opening positioning mesh, it is easy to regulate mesh hole, and mesh opening size is rather accurate, welding aperture could adjust randomly within range.



Application



1. PLC control,with the humanized operation interface, easy to operate and master.
2. The adjustment of mesh specifications uses the touch screen, it is very easy to set the welding parameters and production data.
3. The touch screen adopts Taiwan Delta,it can be of in English.
4. The mesh size can be adjusted to meet the different needs of users.
5. PLC uses the Delta of Taiwan.
6. Inverter adopts HOLIP brand.
7. Mesh drawing car is controlled by Servo motor, improve the accuracy of the mesh effectively.
8. Using the gear and the rack drive, the transmission efficiency is perfect.
9. Mesh can vary to meet the production of a variety of needs.
10. Both ends of the traction device is equipped with limit switches, preventing traction car from crashing and also mechanical damage from collision.



Specification



Automatic Animal Cage Welding Machine Welding For Breed Aquatic Mesh​
Wire diameter 2 .2 - 3 .5mm Line wire feeding Coil wire
Line wire space 50 - 300mm Cross wire feeding Pre - cut wire
Cross wier Space 20 - 300mm Rated capacity 125kva*2
Width of Mesh ≤ 1000mm Input voltage 3 - Phase 380V 50Hz
Welding speed 80 - 110times / min Weight 2.8T



Usage



used to make breed aquatic mesh, poultry mesh, coop, pigeon mesh, rabbit mesh and so on.
