Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine

I'm Online Chat Now

Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine

China Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine supplier
Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine supplier Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine supplier Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine supplier Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine supplier

Large Image :  Adjustable Welding Pressure Wire Mesh Making Machine , Automatic Welded Wire Mesh Machine

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-FM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Servo Motor To Pull Mesh Repeated Automatic Wire Mesh Welding Machine Color: Customer's Requirment
Voltage: 380V Condition: New
Warranty: 1 Year After-sales: Overseas Service Provided
High Light:

steel grating welding machine

,

rebar mesh welding machine

Servo Motor To Pull Mesh Repeated Automatic Wire Mesh Welding Machine





description



High quality to complete the different wire diameter, different mesh mesh welding of various requirements. The device is the most advanced mechanical and electrical integration of welded wire mesh equipment, the biggest advantage is adjustable diameter wire, weft wire diameter input to the computer Can reach the hole distance you reach, if you want to change the hole pitch in the welding wire, you can input the hole pitch into the computer to reach the hole pitch you want, the hole pitch can be adjusted freely.



Application



1. the maximum width of the machine mesh 3.0 meters
2. the welding diameter of 2.5mm-6mm
3.
Transformer Water Cooling
4. a form of welding pressure, sub-control welding
5. the use of the local welding fine-tuning, reducing welding pollution
6. adjustable welding pressure
7. diameter wire size adjustable
8. weft wire pitch automatically change the input computer

9. can be customized according to customer needs.



Specification



Servo Motor To Pull Mesh Repeated Automatic Wire Mesh Welding Machine
Wire diameter 2.5-6mm Longitude Wire Feeding Pre-straighted&pre-cut
Longitude wire space 50-300mm Cross wire feeding Pre-straighted&pre-cut
Cross wire space 25-300mm Rated electrical powe 125kva*6pcs
Width of mesh 2500mm Rated voltage as your request
Welding electrodes 48pcs weight 4T
Welding speed 45-75tines/min Overall size 3m*2*1.8m
Adjustable electromagnetism motor 4.0KW
Can be customized according to customer requirements.



Usage



Water conservancy project, housing construction (floor plate, wall panel), bridge construction, highway construction, airport construction, railway construction, mine protection, which can be widely applied in construction industry.Fence netting (highway, rail road, mountain surrounding and stadium), fence mesh and the production of other protective fences.The production of bird cage, dog cage, various kinds of pet cages and all kinds of breeding cagesThe production of metal furniture, goods shelf, shopping cart and protective cover



packaging



1. Use the steel wire to fasten the easy damages parts to keep its safety and not be hit during the ship
2. The main machine and auxilary equipment with plastic ,then put the spare parts into wooden box
