Home ProductsAutomatic Wire Mesh Welding Machine

Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence

I'm Online Chat Now

Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence

China Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence supplier
Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence supplier Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence supplier Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence supplier Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence supplier

Large Image :  Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence

Product Details:

Place of Origin: Anping Hebei
Brand Name: ChenChengke
Certification: ISO
Model Number: CK-WM-2500

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: no
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30
Contact Now
Detailed Product Description
Product Name: Automatic Anti Climb Fence Wire Fence Welding Machine Control System: PLC
After-sales: Overseas Service Provided Speed: 80-120 (times/minute)
Voltage: 380v Warranty: 1 Year



Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence





 Low Carbon Hot Dipped Galvanized Automatic Anti climb fence Wire Fence Welding Machine





Features


1. International famous trademarks are selected for key driving parts, actuators, and electric/pneumatic components; the life cycle is long, and the precision is high.

Less sparks and low noise during the welding process;

2. Easy operation and simple maintenance;

3. The entirety type foundation for whole machine is easy to install.

4. Reasonable equipment layout and beautiful appearance;

5. Widely used in railway construction projects and civil construction projects and Field Fence.



Specification



Wire diameter 1.5-3mm Line wire feeding Coil wire
Line wire space 50 - 250mm Cross wire feeding Pre - cut wire
Cross wier Space 50 - 250mm Rated capacity 125kva*2
Width of Mesh ≤ 1000mm Input voltage 3 - Phase 380V 50Hz
Welding speed 80 - 90times / min Weight 2.8T



Welding width Max.2500mm(customizable)
Wire diameter 3-6mm
Welding speed 49-90times/min
Line wire distance 50-200mm(customizable)
Voltage 380V 50Hz
Cross wire distance ≥50mm
Can be customized according to customer requirements.



Wire diameter 5-12mm
Cross & Line wire form Pre-straightening and pre-cut wire
Cross wire space 50-200mm
Line wire space 100-200mm
Width of mesh 2500mm
Number of electrodes 24
Welding speed 30-50times/min
Rated voltage 380V-440V
Rate capacity 12*125kva
Operation Touch-screen board
Welding motor Provided by FM speed motor
Cross feeding system Pneumatic system control falling one by one
Mesh pulling system Adopts servo motor to pull mesh sheets repeat
Cooling system Water cooling transformer
Controlling system Synchronous control with PLC program system



Usage



Water conservancy project, housing construction (floor plate, wall panel), bridge construction, highway construction, airport construction, railway construction, mine protection, which can be widely applied in construction industry.Fence netting (highway, rail road, mountain surrounding and stadium), fence mesh and the production of other protective fences.The production of bird cage, dog cage, various kinds of pet cages and all kinds of breeding cagesThe production of metal furniture, goods shelf, shopping cart and protective cover



Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence

Low Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb FenceLow Carbon Hot Dipped Galvanized Wire Mesh Fence Machine Automatic For Anti Climb Fence
