Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise

I'm Online Chat Now

Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise

China Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise supplier
Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise supplier Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise supplier Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise supplier Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise supplier

Large Image :  Firm Welding Spot Fence Mesh Welding Machine 2 M Width High Productivity Low Noise

Product Details:

Place of Origin: Hebei China
Brand Name: ChengKe
Certification: ISO
Model Number: CK-FM-2000Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: plastic warps and plywood box
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 25 Set per month
Contact Now
Detailed Product Description
Color: White Or Blue Product Name: Automatic Double Edge Fence Mesh Welding Machine
Width: 2 M Condition: New
Warranty Period: 1 Year Functions: Welding
High Light:

fence panel making machine

,

hexagonal wire mesh machine

Automatic Double Edge Fence Mesh Welding Machine Production Is Fast , Low Noise





Description



This machine adopts synchronous control technique. The center-control and welding time are composed of PLC program system. The input front-panel has two forms, touch screen and keyboard that makes the machine more intelligent and reasonable and it could press at one time, welding repeatedly. The hopper adopts the step motor; brake motor wheels; pulling the wire net is controlled by the step motor. The line wire and the weft wire are pre-straightened and pre-cut. The longitude wires can be adjustable and cross wire distance can be adjustable according to input the data what you want. The greatest advantage is that you can adjust the distance of weft wire at random on the same piece of wire mesh sheet. The finished product—fence panel is smooth, the error of opposite angle line is small.



advantages


1. the wires feeding automatically
2. it has stable funcation, firm welded point and without welded tracks
3. less noise, higher speed, high efficiency



Specifications



Automatic Double Edge Fence Mesh Welding Machine Production Is Fast , Low Noise
Wire Diameter 2.5mm - 6mm
Width of Mesh 2000m ( can be customize )
Welding Speed 45 - 90 times/min
W elding Aperture 50 * 50 - 200 * 200 ( mm )
Welding Spot 48 ( can be customized )
Rated Voltage 380V



Used



1 . fence mesh for railway, highway, airport bridge and constructions.

2 . Mesh panel for goods shelf and storage racks.
