High Speed Automatic Wire Mesh Welding Machine For Black Wire , PLC Control System

I'm Online Chat Now

High Speed Automatic Wire Mesh Welding Machine For Black Wire , PLC Control System

China High Speed Automatic Wire Mesh Welding Machine For Black Wire  , PLC Control System supplier
High Speed Automatic Wire Mesh Welding Machine For Black Wire  , PLC Control System supplier High Speed Automatic Wire Mesh Welding Machine For Black Wire  , PLC Control System supplier High Speed Automatic Wire Mesh Welding Machine For Black Wire  , PLC Control System supplier High Speed Automatic Wire Mesh Welding Machine For Black Wire  , PLC Control System supplier

Large Image :  High Speed Automatic Wire Mesh Welding Machine For Black Wire , PLC Control System

Product Details:

Place of Origin: Anping Hebei
Brand Name: ChenChengke
Certification: ISO
Model Number: CK-WM-2500

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: no
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30
Contact Now
Detailed Product Description
Product Name: Chengke High Speed Automatic Wire Mesh Welding Machine Voltage: 380V
Control System: PLC Warranty: 1 Year
After-sales: Overseas Service Provided Speed: 80-120 (times/minute)
High Light:

rebar mesh welding machine

,

automatic wire mesh machine



High Speed Automatic Wire Mesh Welding Machine For Black Wire , PLC Control System





    High Speed Black Wire Automatic Wire Mesh Welding Machine Chengke Machine





Specification



Wire diameter 1.5-3mm Line wire feeding Coil wire
Line wire space 50 - 250mm Cross wire feeding Pre - cut wire
Cross wier Space 50 - 250mm Rated capacity 125kva*2
Width of Mesh ≤ 1000mm Input voltage 3 - Phase 380V 50Hz
Welding speed 80 - 90times / min Weight 2.8T



Welding width Max.2500mm(customizable)
Wire diameter 3-6mm
Welding speed 49-90times/min
Line wire distance 50-200mm(customizable)
Voltage 380V 50Hz
Cross wire distance ≥50mm
Can be customized according to customer requirements.



Wire diameter 5-12mm
Cross & Line wire form Pre-straightening and pre-cut wire
Cross wire space 50-200mm
Line wire space 100-200mm
Width of mesh 2500mm
Number of electrodes 24
Welding speed 30-50times/min
Rated voltage 380V-440V
Rate capacity 12*125kva
Operation Touch-screen board
Welding motor Provided by FM speed motor
Cross feeding system Pneumatic system control falling one by one
Mesh pulling system Adopts servo motor to pull mesh sheets repeat
Cooling system Water cooling transformer
Controlling system Synchronous control with PLC program system



description



This machine has multi spot welding function, advanced control system enables the machine to weld the mesh in any sequence or any way. Using high quality air cylinder to provide welding force, the output is much more stable and durable than conventional mechanical type welding machines.Also machine features can be made by your idea together with our engineer technique support.Varies materials can be welded: weld mild steel wire, stainless wire, galvanized steel wire.Mesh panels: weld construction mesh panel, fridge shelf panel, shelf rack mesh panel, reinforcing mesh panelsMesh production line: producing rolled mesh in varies size.All kinds of mesh products: weld cage for bird, pet cage welding, mesh trolley welding, weld wire mesh basket, wire tray, fridge condensers, cable tray mesh etc.



Usage



Water conservancy project, housing construction (floor plate, wall panel), bridge construction, highway construction, airport construction, railway construction, mine protection, which can be widely applied in construction industry.Fence netting (highway, rail road, mountain surrounding and stadium), fence mesh and the production of other protective fences.The production of bird cage, dog cage, various kinds of pet cages and all kinds of breeding cagesThe production of metal furniture, goods shelf, shopping cart and protective cover
