Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters

I'm Online Chat Now

Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters

China Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters supplier
Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters supplier Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters supplier Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters supplier Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters supplier

Large Image :  Stainless Steel Wire Automatic Wire Mesh Welding Machine Intelligent Width 3.0 Meters

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-FM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Galvanized Wire / Stainless Steel Wire / Black Wire Automatic Wire Mesh Welding Machine Color: Customer's Requirment
Voltage: 380V Speed: 50-80 (times/minute)
Warranty: 1 Year After-sales: Overseas Service Provided

Galvanized Wire / stainless steel wire / black wire Automatic Wire Mesh Welding Machine





description



1), This kind of machine is expert to produce mesh sheet. The finished mesh is much smoother than mechanical machines products.

2), PLC control. Easy to set and control. It makes this machine more intelligent and reasonable.

3), The weft wire supply is automatic.

4), The greatest advantage is possible to adjust the distance of wefts at random on the same mesh sheet

5) the finished produce welded wire mesh are for fence, construction, poultry cage etc



Application



1, the maximum width of the machine mesh 3.0 meters
2, the welding diameter of 2.5mm-6mm
3, welding transformer air since cold
4, a form of welding pressure, sub-control welding
5, the use of the local welding fine-tuning, reducing welding pollution
6, adjustable welding pressure
7, diameter wire size adjustable
8, weft wire pitch automatically change the input computer

9.can be customized according to customer needs.



Usage



Highway , railway and various function of protection . For construction which used for basis of high building , roof mesh , floor mesh . It is also widely used in agriculture and poultry mesh , farming mesh and so on .



Specification



Galvanized Wire / stainless steel wire / black wire Automatic Wire Mesh Welding Machine
Wire diameter 2.5-6mm Longitude Wire Feeding Pre-straighted&pre-cut
Longitude wire space 50-300mm Cross wire feeding Pre-straighted&pre-cut
Cross wire space 25-300mm Rated electrical powe 125kva*6pcs
Width of mesh 2500mm Rated voltage as your request
Welding electrodes 48pcs weight 4T
Welding speed 45-75tines/min Overall size 3m*2*1.8m
Adjustable electromagnetism motor 4.0KW
Can be customized according to customer requirements.
