intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages

I'm Online Chat Now

intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages

China intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages supplier
intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages supplier intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages supplier intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages supplier intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages supplier

Large Image :  intelligent Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-FM

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Automatic Chicken Cage Welding Machine Welding Aperture: 50x50-200x200mm
Voltage: 380V Color: Blue,white
Warranty: 1 Year After-sales: Overseas Service Provided

Automatic Wire Mesh Welding Machine For Making Animal / Pet / Poultry Mesh Cages





description



This machine adopts electrical and electronic synchronous control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit. This operation is accurate, it has stable function , firm welded point, without welded tracks. Not only welding speed is fast, but also it is easy to learn and operate. The machine is equipped with precise equipment for weft cutting and positioning, so the length of wefts is identical and regular , it is unnecessary to slice the side . Drawing mesh system adopts elastic tension and opening positioning mesh, it is easy to regulate mesh hole , and mesh opening size is rather accurate, welding aperture could adjust randomly within range.



Application



1. PLC control,with the humanized operation interface, easy to operate and master.
2.The adjustment of mesh specifications uses the touch screen, it is very easy to set the welding parameters and production data.
3.The touch screen adopts Taiwan Delta,it can be of in English.
4.The mesh size can be adjusted to meet the different needs of users.
5. PLC uses the Delta of Taiwan.
6. Inverter adopts HOLIP brand.
7. Mesh drawing car is controlled by Servo motor, improve the accuracy of the mesh effectively.
8.Using the gear and the rack drive, the transmission efficiency is perfect.
9. Mesh can vary to meet the production of a variety of needs.
10.Both ends of the traction device is equipped with limit switches, preventing traction car from crashing and also mechanical damage from collision.



Specification



Wire diameter 2 .2 - 3 .5mm Line wire feeding Coil wire
Line wire space 50 - 300mm Cross wire feeding Pre - cut wire
Cross wier Space 20 - 300mm Rated capacity 125kva*2
Width of Mesh ≤ 1000mm Input voltage 3 - Phase 380V 50Hz
Welding speed 80 - 110times / min Weight 2.8T



Usage



Breed aquatic mesh ( poultry mesh , pigeon mesh, rabbit mesh , fox mesh and so on )
Building mesh ( reinforcing construction mesh , floor warning mesh , seed-bed mesh and room mesh )
