| Condition: | New | Wire Diameter: | 2.5-4.0mm |
|---|---|---|---|
| Warranty: | 1 Year | After-sales: | Overseas Service Provided |
| Voltage: | 38V | Product Name: | Galvanizing Steel Wire Machine |
| High Light: | hot dip galvanizing machine,hot dip galvanizing equipment |
||
Galvanizing Steel Wire Machine With Widely In Wire Mesh Welding Machine
Description
1. Pay off and take up
The pay off adopts vertical axis type with diameter 550 mm, and take up adopt 550 coiler take up.
2. Closed type electrolytic degreasing device
Adopt negative electricity degreasing, the capacity of rectifier is 500A/12V, the liquid circulate by magnetic drive pump. The bottom kerve can be moved which is more convenient for cleaning.
3. Neutralization and water washing tank
All adopt magnetic drive pump for circulating, sewage discharge regularly, reduce the waste water.
4. Electrolytic acid pickling tank
It adopts all closed type, the roller is made by #316 stainless steel, and capacity of rectifier is 500A/12V. The magnetic drive pump is used for the circulating of the acid liquid, the arrangement of copper bar according to the capacity of the rectifier. The bottom kerve can be moved which is more convenient for cleaning.
5. Thickness zinc coating tank
It adopts all closed type, the roller is made by #316 stainless steel, and capacity of rectifier is 8000A/12V. The arrangement of copper bar according to the capacity of the rectifier, anode material is titanium plate whose size is 5*50 mm, and magnetic drive pump is used for the circulating, the effective length of galvanizing is 250 meters.
6. Bright zinc coating tank
It adopts all closed type, the roller is made by #304 stainless steel, and capacity of rectifier is 500A/12V. Anode material is titanium plate whose size is 5*50 mm, and magnetic drive pump is used for the circulating.
7. Baking device
Short circuit baking is adopted, the temperature is adjusted by voltage regulator, which is low power consumption, heating up fast, and safe.
Features
The total length of production line is very short, no need large space of workshopNeeded little zinc block and chemical raw material, which can reduce needed circulating funds.The zinc coating quality of steel wire is also easy for control.Have little pollution, high efficiency, and little investment.One machine only need one operator
Specification
| 1 | Power source | 380V/50HZ |
| 2 | Working diameter | 2.0-5.0 mm |
| 3 | Galvanizing thickness | Less than 300 g/m2 |
| 4 | Galvanizing speed | 50 m/min (thickness 285 g/m2) |
| 80 m/min (thickness 170 g/m2) | ||
| 100 m/min (thickness 60 g/m2) | ||
| 5 | Pay off type | Vertical axis pay off |
| 6 | Diameter of pay off | 550 mm |
| 7 | Take up type | Coiler take-up |
| 8 | Diameter of take up | 550 mm |
| 9 | Power capacity | 90 kw |
| 10 | Length of equipment | 28 m |
Processing step
Vertical axis pay-off → Tension → Electrolytic degreasing → Neutralization → Water washing → Electrolytic acid pickling → Water washing → Thickness zinc coating → Water washing → Bright zinc coating → Water washing → Hot water washing → Baking → Coiler take-up
