PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot

I'm Online Chat Now

PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot

China PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot supplier
PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot supplier PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot supplier PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot supplier PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot supplier

Large Image :  PLC Control Construction Mesh Welding Machine Mesh Width 1200mm Firm Welding Spot

Product Details:

Place of Origin: Hebei China
Brand Name: Chengke
Certification: ISO
Model Number: CK - CM - 2500Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: 1.Main machine is in nude package. 2.Spare parts and control cabinet are packed with wooden box.
Delivery Time: 15 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 25 Sets
Contact Now
Detailed Product Description
Color: Customer's Requirment Wire Diameter: 3-5mm
Product Name: Building Mesh Welding Machine After-sales: Engineers Available To Service Machinery Overseas
Mesh Hole: 50-200mm Speed: 50-80Times/min

Building Mesh Welding Machine With shearing machine with automatic falling Mesh





Description



1. Less sparks and low noise during the welding process;

2. Easy operation and simple maintenance;

3. The entirety type foundation for whole machine is easy to install.

4. Reasonable equipment layout and beautiful appearance;



Features



The machine welding system adopts synchronous control technique, welding time and sub-control welding are all composed of digital integrated circuit, which has stable function, firm welded points and without welded tracks. The control cabinet is button control. The greatest advantage of this machine is you can adjust the distance of weft wire at random on the same piece wire mesh panel.



Used



It is used widely in industry and construction, such as building board, the roof, the wall, the bridge, concreteroad, the floor, the airport, cement pipe, concrete prefabricated components, retaining wall, protection slope, the tunnel, the dock, the dyke and so on



parameters



Building Mesh Welding Machine With shearing machine with automatic falling Mesh
Item CK-1200 CK-1600 CK-2100 CK-2500
Number of Electrodes 24 32 40 48
Max. Mesh Width 1200mm 1600mm 2100mm 2500mm
Wire Diameter 3-5mm 3-5mm 3-5mm 3-5mm
Mesh Length 3-12m 3-12m 3-12m 3-12m
Cross Wire Space 50-200mm 50-200mm 50-200mm 50-200mm
Line Wire Space 50-200mm 50-200mm 50-200mm 50-200mm
Electric Capacity ≥160KVA ≥160KVA ≥160KVA ≥160KVA
Welding Speed 60t/min 60t/min 60t/min 60t/min
Control System PLC Control PLC Control PLC Control PLC Control
Special specification is available according to your requirements.
