High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity

I'm Online Chat Now

High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity

China High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity supplier
High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity supplier High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity supplier High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity supplier

Large Image :  High Standard Electro Galvanized Wire Machine 2.5 - 4.0mm High Production Capacity

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-GE

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Works day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3 Sets
Contact Now
Detailed Product Description
Condition: New Wire Diameter: 2.5-4.0mm
Warranty: 1 Year After-sales: Overseas Service Provided
Galvanized Type: Electro Galvanized Product Name: Galvanized Steel Wire Production Machine

Galvanized Steel Wire Production Machine With High Production Capacity





Description



1. Eqipped with solution recycling and filtering device, in time filtering to make sure solution clean

2. Equipped with PH aotomatic detecting device and automatic adding acid calulation device, to make sure keep a relatively constant PH value

3. Equipped with solution heat exchanger, to make sure solution keep a relatively constant temperature

4. Automatic level control

5. Constant voltage or constant current control, site center control for general lines, can start, stop or adjust separately for each rectifier

6. Equipped with current sensor, can real-time monitor each cathode roller

7. Main control instrument: international famous brand, system running is stable, safe and reliable

8. Humanized design and safe function design, to achieve convenient site operation and maintenance.

9. Low ordinary maintenance cost



Features



1. The total length of production line is very short, no need large space of workshop

2. Needed little zinc block and chemical raw material, which can reduce needed circulating funds.

3. The zinc coating quality of steel wire is also easy for control.

4. Have little pollution, high efficiency, and little investment.

5. One machine only need one operator



Specification



1 Quantity of line pc 12-24
2 Wire diameter mm 1.4-4.0
3 Material of wire   Low carbon
4 Thickness g/m2 15- 40
5 Working speed m/min 35-40 (frequency control)
6 Capacity ton/h 1 ton/hour (2.0mm steel wire)
7 Equipment length m 55
8 Electric capacity kw 65
9 Diameter of take up mm 550
