Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence

I'm Online Chat Now

Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence

China Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence supplier
Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence supplier Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence supplier Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence supplier Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence supplier

Large Image :  Automatic Grassland Fence Machine Hinge Joint Weaving For Making Cattle Field Farm Fence

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-GF

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Works day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Sets
Contact Now
Detailed Product Description
Product Name: Automatic Hinge Joint Weaving Wire Mesh Machine Speed: 45-60 Times/min
Wire Diameter: 1.9-2.5 Mm Edge Diameter: 2.0-3.5 Mm
After-sales: Overseas Service Provided Condition: New

Automatic Hinge Joint Weaving Wire Mesh Machine For Making Cattle Field Farm Fence





presentation



1.Install:The machine need not install the anchor bolt, only need to put on the ground of plant. it is easy to install. we will send the specification to you.

2.Adjust: All the debugging working will be done in factory manufacture by our engineers.

3.Production capacity: 400m/h

4.Width: 1.0-2.4m

5.The machine's power: 5.5kw, 7.5kw, 11kw.

6.Accessories: wire bobbin, reel, tool box, etc. the accessories free offer to you.


advantages



1.Adops sophisticated computer control, advanced production technology.

It can weave the weft and warp wire automatically together to form the field fences.

2.Reliable property, high efficient, simple operation, low-cost maintenance.

3.The finished products enjoy innovative structure, firm and precise weaving,neat and beautiful

and diverse specifications. HINGE JOINT:savings worth the price to have.

4.Material: galvanized wire, low-carbon steel wire, steel wire, iron wire.

e.



Parameters



Production specification CY-A CY-B CY-C
Power 5.5KW 7.5KW 7.5KW
Speed ≤45knock/min ≤45knock/min ≤45knock/min
Wire diameter 1.9mm-2.5mm 1.9mm-2.5mm 1.9mm-2.5mm
Top/bottom diameter 2.0mm-3.5mm 2.0mm-3.5mm 2.0mm-3.5mm
Voltage 380V-3P-50HZ 380V-3P-50HZ 380V-3P-50HZ
Weight 3.5T 3.8T 4.0T
Overall dimension 2.8 x 3.2 x 2.4(M) 3.3 x 3.2 x 2.4(M) 3.4 x 3.2x 2.4(M)



used



Zoo fence Construction site fences backyard birds slope greening landscape with a net, a wildlife park grassland pasture and other places of grazing in captivity, especially applied in the pasture fence project, for a rotational grazing grassland protection, can play an important role, can also be used for rare flowers The isolation protection forest planting zone.
