Home ProductsBrick Force Wire Making Machine

Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life

I'm Online Chat Now

Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life

China Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life supplier
Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life supplier Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life supplier Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life supplier Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life supplier

Large Image :  Low Maintenance Brick Force Wire Making Machine PLC Control Long Service Life

Product Details:

Place of Origin: Hebei China
Brand Name: ChengKe
Certification: ISO
Model Number: CK-BM-780Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: NO
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, , Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Concrete Reinforcement Steel Wire Mesh Machine Mesh Width: 780 Mm
Wire Diameter: 1.5-3mm Speed: 40-50times/min
Lvoltage: 380V 3phase 50HZ Warranty: 1 Year

Automatic Concrete Reinforcement Steel wire Mesh Machine Stable Function





description



1. wire dia:2-3 mm ,
the cross spacing : 57mm,75mm,230mm
the line spacing :300mm

2. wire dia:1.5-2.5mm
the cross spacing:115mm,230mm
the line spacing :300mm

Both machine could produce three pieces of wire mesh at the same time.Each piece of mesh have 8mm extra length at both side.
The available wire is black wire or galvanized wire.



Features



The machine adopts electrical synchronous control technique,both welding time and cent-control welding is composed of digital and integrated electric circuit.This is operation is accurate, it has stable function,firm welded point and without welded tracks. Not only welding speed is fast but also it is easy to learn and operate.It is easy to regulate mesh hole and mesh size is rather accurate,welding aperture could also adjust rand only within the range.



Usage



Used with concrete in buildings and construction, maintenance of equipments, making of arts and crafts, covering screen for first class sound case. Also fencing for super highway, studio, highway. Heavy expanded metal can be used as step mesh of oil tanks, working platform, corridor and walking road for heavy model equipment, boiler, petroleum and mine well, automobilevehicles, big ships.



Packaging



1. The main body of the wire mesh welding machine will be packaged with plastic.

2. The anther parts of the wire mesh welding machine,will be packaged with cartons,they will be protected well.

3. The spare parts of the wire mesh welding machine will be packaged in the wooden cases.

4. Only this type wire mesh welding machine will need a 20' container loading.

5. If you have another package requirements,we will change it .

6. We will supply the best package for you.



Specification



Automatic Concrete Reinforcement Steel wire Mesh Machine Stable Function
Welding wire diameter Φ1.6MM-Φ2.5MM
Space of cross wires 50-400mm
Space of line wires 250~300mm
welding width 300mm
Seep of Welding 45times/min
Nominal voltage 380V 3phase 50HZ
Nominal power 72KVA
