Product Details:
Payment & Shipping Terms:
|
| Product Name: | Chicken Cage Welding Machine | Wire Diameter: | 1.5-3mm |
|---|---|---|---|
| Warranty: | 1 Year | After-sales: | Engineers Available To Service Machinery Overseas |
| Wire Space: | 50-200mm | Speedy: | 40-60times/min |
| High Light: | chicken wire mesh machine,wire cage welding machine |
||
Automatic Wire Mesh Metal Chicken Cage Welding Machine AC 380V
description
1. This pets cage welding machine is automatically welding machine used for poultry cage wire diameter 1.5-3.2mm.
2. The pets cage welding machine adapts electrical synchronous technique.
3. The welding time and seperate welding of pets cage welding machine is controlled by digital electric circuit.
4. The pets cage welding machine makes sure of the line and cross wires be solid mesh in the principle of multi-electrode resistance welding.
5. The pets cage welding machine consists of welding machine, line and cross wires feeding device, mesh stepping system and electrical control system.
6. The material of pets cage welding machine can be low carbon steel wire or galvanized wire.
7. The line wires of pets cage welding machine are in coil and can be straightened by straightening wheel on the front of the machine and then be put into the line wire entrance.
Cross wires of pets cage welding machine are pre-straight and cut wires.
8. The mesh aperture size of pets cage welding machine can be adjusted. The line wire space can be adjusted through adjusting the electrode space. The cross wires space can be adjusted by PLC control system.
9. The welding speed of pets cage welding machine can be 60times/min, the work speed mainly depends on the wire material,mesh aperture, choice of welding parameter, proficiency of workers,etc
10. The finished product of pets cage welding machine can be in roll or in panel.
Features
1. Business model:factory direct sale
2. Professional manufacture
3. No environment pollution
4. Smooth and beautiful welding spots
5. Product quality assurance
6. Available to weld multiple work pieces and heads in high efficiency
7. With credibility and protection
8. Good after sale service
Packing
1 . The spare parts and control cabinet will be loaded in wooden box.
2 . The main machine is nude packing or plastic packing
Specification
| Automatic Wire Mesh Metal Chicken Cage Welding Machine AC 380V | ||
| Model | CK-AC-1 | CK-AC-2 |
| Input power | 380V 50 Hz | 380V 50 Hz |
| Max. width | 1200mm | 1200mm |
| Line wire space | 25—200mm | 25—200mm |
| Cross wire space | 25—200mm | 25—200mm |
| Line wire diameter | 1.8-3.0mm | 1.8-3.0mm |
| Cross wire diameter | 1.8-2.5mm | 1.8-2.5mm |
| Rated capacity | 60kva*2 | 60kva*2 |
| Welding point No. | 16 | 16 |
| Motor power | 2.2kw | 2.2kw |
| Feed line wire | Coils wire | Coils wire |
| Feed cross wire | Coil wire | Coils wire & pre-cut wire |
| Welding speed | 40-50times/min | 50-60times/min |
Service
Pre-Sales Service:
Inquiry and consulting support.
Sample testing support.
View our Factory.
Online visit
After-Sales Service:
Training how to install,operate and maintain the machine.
Engineers available to service machinery overseas.
One year gurantee for the whole machine.
Operation manual is availabl
Sincerely look forward to cooperate with you ! For more details about wire mesh welding machine, welcome to contact with us in any time ! We will fully committed to provide the best quality products and services.
