High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture

I'm Online Chat Now

High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture

China High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture supplier
High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture supplier High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture supplier High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture supplier High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture supplier

Large Image :  High Output Chicken Cage Welding Machine 50 X 50 - 200 X 200mm Welding Aperture

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: JK - AC - 1200Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: with plastic package
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Chicken Layer Cage Welding Machine Usage: Welding Cage Mesh
Warranty: 1 Year After-sales: Engineers Available To Service Machinery Overseas
Welding Aperture: 50x50-200x200mm Voltage: 380V

Chicken Layer Cage Welding Machine / Welded Chicken Cage Wire Mesh Machine





description



This machine adopts electrical and electronic synchronous control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit. This operation is accurate, it has stable function , firm welded point, without welded tracks. Not only welding speed is fast, but also it is easy to learn and operate. The machine is equipped with precise equipment for weft cutting and positioning, so the length of wefts is identical and regular , it is unnecessary to slice the side . Drawing mesh system adopts elastic tension and opening positioning mesh, it is easy to regulate mesh hole , and mesh opening size is rather accurate, welding aperture could adjust randomly within range.



Features



1. This pets cage welding machine is automatically welding machine used for poultry cage wire diameter 1. 5-3.2mm.

2. The pets cage welding machine adapts electrical synchronous technique.

3. The welding time and seperate welding of pets cage welding machine is controlled by digital electric circuit.

4. The pets cage welding machine makes sure of the line and cross wires be solid mesh in the principle of multi-electrode resistance welding.

5.The pets cage welding machine consists of welding machine, line and cross wires feeding device, mesh stepping system and electrical control system.

6. The material of pets cage welding machine can be low carbon steel wire or galvanized wire.

7. The line wires of pets cage welding machine are in coil and can be straightened by straightening wheel on the front of the machine and then be put into the line wire entrance.

Cross wires of pets cage welding machine are pre-straight and cut wires.

8. The mesh aperture size of pets cage welding machine can be adjusted. The line wire space can be adjusted through adjusting the electrode space. The cross wires space can be adjusted by PLC control system.

9. The welding speed of pets cage welding machine can be 60times/min, the work speed mainly depends on the wire material,mesh aperture, choice of welding parameter, proficiency of workers,etc

10. The finished product of pets cage welding machine can be in roll or in panel.



Usage



Breed aquatic mesh ( poultry mesh , pigeon mesh, rabbit mesh , fox mesh and so on )
Building mesh ( reinforcing construction mesh , floor warning mesh , seed-bed mesh and room mesh )



Packing



1 . The spare parts and control cabinet will be loaded in wooden box.
2 . The main machine is nude packing or plastic packing



Specification



Model CK-AC
Wire diameter 2.2-3.5mm
Longitude wire space 50-200mm
Cross wire space min. 20mm or smaller
Mesh width max. 1200mm/1500mm
Longitude wire feeding from wire coils
Cross wire feeding pre-straightened&pre-cut
Welding speed 80-110 times/min
Welding transformer 125*2/3/4 pcs



Service



Pre-Sales Service:

Inquiry and consulting support.

Sample testing support.

View our Factory.

Online visit

After-Sales Service:

Training how to install,operate and maintain the machine.

Engineers available to service machinery overseas.

One year gurantee for the whole machine.

Operation manual is availabl
