Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine

I'm Online Chat Now

Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine

China Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine supplier
Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine supplier Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine supplier Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine supplier Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine supplier

Large Image :  Sturdy Structure Chicken Mesh Making Machine , Stainless Steel Wire Mesh Machine

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: JK - AC - 1200Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: with plastic package
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Animal Cage Welding Machine Inery Overseas Wire Diameter:: 2-3.2
Warranty: 1 Year After-sales: Engineers Available To Service Machinery Overseas
Welding Speed: 45-60 Times/minute Voltage: 380V

No burn marks And Size Precision Chicken Cage Welding Machine







description



This machine adopts synchronous control technology, power electronics and control welding time welding are all composed of digital integrated circuit, high control precision, stable performance, solder joint is firm, no burn marks blanking uniform accurate, mesh is neat, without cutting the grid size precision is high, the welding aperture can be adjusted arbitrarily within the specified scope



Features



Breeding net plane belongs to the industry a welding net machine, its main features are: bar for wire plate into the expected, the horizontal line for broken wires into the material, can be continuous production piece of mesh or volume mesh according to different divided into mechanical Seine net mechanism and numerical control net two types, mechanical Seine machines main function structure and architectural mesh welding machine, the same numerical control net main function structure models are: bar straightening device ordinate positioning mechanism, horizontal l hopper, numerical control net







Specification



No burn marks And Size Precision Chicken Cage Welding Machine
Model CK-AC-1 CK-AC-2
Input power 380V 50 Hz 380V 50 Hz
Max. width 1200mm 1200mm
Line wire space 25—200mm 25—200mm
Cross wire space 25—200mm 25—200mm
Line wire diameter 1.8-3.0mm 1.8-3.0mm
Cross wire diameter 1.8-2.5mm 1.8-2.5mm
Rated capacity 60kva*2 60kva*2
Welding point No. 16 16
Motor power 2.2kw 2.2kw
Feed line wire Coils wire Coils wire
Feed cross wire Coil wire Coils wire & pre-cut wire
Welding speed 40-50times/min 50-60times/min



Packing



1 . The spare parts and control cabinet will be loaded in wooden box.
2 . The main machine is nude packing or plastic packing
