Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life

I'm Online Chat Now

Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life

China Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life supplier
Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life supplier Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life supplier Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life supplier Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life supplier

Large Image :  Galvanized Mesh Chicken Cage Welding Machine Energy Saving Long Service Life

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: JK - AC - 1200Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: with plastic package
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Poultry Cage Welding Machine Cross Wire Space: Min. 25mm
Warranty: 1 Year After-sales: Engineers Available To Service Machinery Overseas
Galvanized Mesh Poultry Cage Welding Machine: 50-200mm Voltage: 380V
High Light:

chicken wire mesh machine

,

chicken mesh making machine

Galvanized mesh Chicken Cage Welding Machine For Making poultry cage





description



This machine adopts electrical and electronic synchronous control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit. This operation is accurate, it has stable function , firm welded point, without welded tracks. Not only welding speed is fast, but also it is easy to learn and operate. The machine is equipped with precise equipment for weft cutting and positioning, so the length of wefts is identical and regular , it is unnecessary to slice the side . Drawing mesh system adopts elastic tension and opening positioning mesh, it is easy to regulate mesh hole , and mesh opening size is rather accurate, welding aperture could adjust randomly within range.



Features



The machine is made of thick steel plate and profile steel, high strength, high toughness, main structure more solid.The welding adopts synchronous power control and separate-control, making the welding transformers working separately to reduce the capacity requirement of power transformer, reduce the impact current.The cross wire space adjustment adopts PLC micro-computer control, set on the touch screen.The mesh pulling system in cycle is automatically calculated. The mesh pulling car can pulling mesh by the cycle automatically.The machine will stop working automatically if there is no cross wires in hopper device.The cutting machine can cut the mesh as demand length automatically.



Specification



Galvanized mesh Chicken Cage Welding Machine For Making poultry cage

Wire diameter 2 - 4mm Line wire feeding Coil wire
Line wire space 50 - 300mm Cross wire feeding Pre - cut wire
Cross wier Space 20 - 300mm Rated capacity 125kva*2
Width of Mesh ≤ 1000mm Input voltage 3 - Phase 380V 50Hz
Welding speed 80 - 110times / min Weight 2.8T



Packing



1 . The spare parts and control cabinet will be loaded in wooden box.
2 . The main machine is nude packing or plastic packing
