High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance

I'm Online Chat Now

High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance

China High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance supplier
High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance supplier High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance supplier High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance supplier

Large Image :  High Efficiency Chicken Cage Welding Machine / Fencing Net Making Machine Low Maintenance

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: JK - AC - 1200Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: with plastic package
Delivery Time: 15 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 25 Ssts
Contact Now
Detailed Product Description
Color: White,blue Condition: New
Warranty: 1 Year After-sales: Engineers Available To Service Machinery Overseas
Application: Fence & Construction Mesh Type: Roll & Panel

Automatic Animal Cages Welding Machine Chicken cages - JK - AC-1200Q





Specifications



1 . wire diameter ,  2 - 3 . 2mm

2 . line wire from , coil wire.

cross wire from , pre - cut wire

3 . control system , synchronous control with PLC , touch screen board

4 . firm welding , little noise , high speed

5 . finished Production , panel mesh



Basic Info



1 . The machine is used for fence 2 - 3 . 2mm , and it is an automatic equipment designed and manufactured by ourselves absorbing advanced resistance welding technology from home and abroad .
2 . The machine uses electrical and electronics synchronous control technique , welding time and separate welding adopt digital and integrated electric circuit .
3 . Air pressure control cross wire automatic falling one by one .
4 . Welding pressure are provided by pneumatic pressure system , uniform pressure and stable performance .
5 . The air cylinder controls the rod for pulling the mesh , which is easy to regulate mesh hole and mesh opening size is rather accurate , welding aperture could adjust randomly with certain range .



Application



Breed aquatic mesh ( poultry mesh , pigeon mesh, rabbit mesh , fox mesh and so on )
Building mesh ( reinforcing construction mesh , floor warning mesh , seed-bed mesh and room mesh )



Packing & Shipping



1 . The spare parts and control cabinet will be loaded in wooden box.
2 . The main machine is nude packing or plastic packing



Wire diameter 2 .2 - 3 .5mm Line wire feeding Coil wire
Line wire space 50 - 300mm Cross wire feeding Pre - cut wire
Cross wier Space 20 - 300mm Rated capacity 125kva*2
Width of Mesh ≤ 1000mm Input voltage 3 - Phase 380V 50Hz
Welding speed 80 - 110times / min Weight 2.8T





Customers notices



Each equipment with different specifications .
Therefore , we need you to send us specific inquiry , then we can quote better price and suitable detailed information according to your specific technical data and requirements .



Parameter includes



1 . Mesh panel wire diameter , from  ___ mm to  ___ mm

2 . Mesh opening size , from  ___ mm to  ____ mm

3 . Would you like mesh panel or mesh rolls ?

4 . Max . Wire mesh width ?
