PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient

I'm Online Chat Now

PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient

China PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient supplier
PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient supplier PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient supplier PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient supplier PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient supplier

Large Image :  PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient

Product Details:

Place of Origin: Anping China
Brand Name: chengke
Certification: ISO
Model Number: CK-CL-2000

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 1000-10000 USD
Packaging Details: no
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union
Contact Now
Detailed Product Description
Name: PLC Control Chain Link Fence Weaving Machine Color: White And Blue
Wire Dia: 1.8mm-4.0mm Mesh: 30mm-100mm
Weight: 4T After-sales: Provide Overseas Services

PLC Control Fully Automatic single wire Chain Link Fence Machine fast and efficient



presentation



1. The chain link is automatically formed into rolls while the desired length is over.

2. Manufacturing chain link fences of different sizes.

3. Sides of chain link fence can be twisted or knuckled as required.

4. This machine is equipped with PLC (programmable Logic Controller), only one can operate it.

Working principle

The wire is taken in from payoff stand and transported into dies where Diamond Size takes shape.

Finished wire is stitched as diamond holes.

At last, the chain link is automatically rolled by receiving wheels.



Our Advantage:

1. We have more than 12 years of experience producing chain link machine. The machine can running very well.
2. You can use our machine directly once you get electricity. No need to connect wires or adjust the machine. Which can save your time and overseas service cost.
3. We use Servo Motor on the machine. As result, the machine can running very fast and lso you can adjust many things through the PLC.
4. We using big and thick frame tube on the machine. Moveover, E-coating will be used as the machine surface finish. As a result, the machine produced by us is very strong and realy beautiful.
Welcome you to contact us to get our machine photoes or videos.



The Main Parameters



Maximun wire diameter 4.0 mm
Minimum wire diameter 1.5 mm
Maximum Mesh Size 100 mm
Minimum Mesh Size 40 mm
Machine Width 2 m--6 m
Volts Power

220V, 380V, 415V, 440V, etc.

(According to your requirement)

HZ Power

50hz, 60hz, etc.

(According to your requirement)

Phrase

3

(According to your requirement)

Mesh Edge Over lock or twist
Total Power 11 kw



Usage



Chain Link Fence are widely use in animal husbandry, sports place, road greening defense, highway barrier, airport, port, residence, etc.
