CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min

I'm Online Chat Now

CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min

China CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min supplier
CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min supplier CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min supplier CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min supplier CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min supplier

Large Image :  CNC Operating System Wire Rod Straightening Machine 380v Speed 30 M / Min

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-WS

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Works day
Payment Terms: L/C, T/T, , Western Union
Supply Ability: 30 Sets
Contact Now
Detailed Product Description
Condition: New Speed: 30 M/min
Voltage: 380v Product Name: CNC Operating System Wire Rod Straightening And Cutting Machine
Warranty: 1 Year After-sales: Overseas Service Provided

CNC Operating System Wire Rod Straightening And Cutting Machine



description



Our wire straightening and cutting machine has been sold to many countries all over the world and got good feed back from our customers because its high quality and excellent performance

The straightening-cutting machine can cut Stainless Steel wire, aluminum wire, hard-drawn wire, PVC steel wire and so on. It is  small, solid, better lubricant, little power loss, operation easy, high efficiency, convenient for moving and the knife can be controlled by manual. And the Cut is nice, have close tolerance and good performance.


Features



1. Adopting adjustable speed traction to ensure the reliability of the feeding and avoid damaging the steel bar .

2. Straightening wheel, square blade and round blade are high quality alloy steel after heat treatment, which can

work under heavy load and have a long service life.

3. This machine adopts CNC operating system, which can automatically stop working after completing the stated number .

4. The machine is zero error form .It saves more materials than the old machine.



Used



The wire cutting machine is used to straightening galvanized wire or rebar, and then cut it into the needed length. It can do a prepare work for the wire mesh welding machine. So it is widely accepted to the factory who is dealing wire wires and wire mesh. Also widely used in construction area.



parameters



Model CK1.5-3.5 CK2-5 CK3-6 CK3-6 CK4-12
Wire diameter mm 1.5-3.5mm 2-5 3-6 3-6 4-12
Cut length mm 30-2000 30-6000 30-6000 Max.6M Max.12M
Error tolerance mm 1 1 1 1 5mm
Speed M/minute 25 30 36 40-130M 40-120M
Straight motor kw 1 1.5 3 11 14
Cut motor kw 0.75 0.75 1.5 4 5
