Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing

I'm Online Chat Now

Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing

China Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing supplier
Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing supplier Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing supplier Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing supplier Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing supplier

Large Image :  Electric Resistance Spot Welding Machine Low Power Consumption For Wire Mesh Processing

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-SW-20Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Condition: New Voltage: 380V
Warranty: 1 Year Product Name: Pneumatic Electric Resistance Spot Welding Machine
Color: Customer's Requirment After-sales: Overseas Service Provided
High Light:

pneumatic spot welding machine

,

water cooled spot welder

Pneumatic Electric Resistance Spot Welding Machine Used For Wire Mesh Processing





description



Low power consumption of main transformer
Easy operation and maintenance with pedal-level type spring-press structure
Adjustable welding time, easy welding repeated
Suitable for low carbon steel, wire, stainless steel plate.



Features



a. Three control functions: constant primary and secondary current, constant voltage;
b. Automatic adjustment of welding power and welding current;
c. Ensure the automatic cycle of each program segment of welding process in order to achieve complete automation;
d. When the current is too low, it will automatically electrify to conduct repair welding;
e.Be able to use the control panel to set parameters for different welding models directly. Convenient operation, easy adjustment;
f. Both single welding and continuous welding are available and each welding cycle has three welding conditions;
g. The intensity and time of welding current of each welding condition could be set separately. In the meantime, the current could be set to gradual up or down;
h. Pneumatic control (action output); the pneumatic control could be delayed;
i.Be able to store 9 types of welding models. Be able to select and adjust different welding models by choosing the number of models;
j. Silicon controlled adopts phase shift to trigger and the synchronous voltage is from the network voltage to ensure the silicon controlled and network will conduct synchronous phase shift trigger so as to achieve precise adjustment of the welding current and to meet the requirement of welding different materials;
k.When the network voltage fluctuates, the automatically compensation can make the welding current more stable. Thus, the welding quality could be guaranteed even though the network voltage is under bad situation.



Use


Welding machine assembly of the appropriate electrode form and controller, to meet a variety of wire mesh basket products, steel mesh, pipe products such as processing and manufacturing. Can be carbon steel, stainless steel, galvanized steel and a variety of non-ferrous metal wire, pipe, sheet, screw and other spot welding and row welding.



Specification



AC Foot Operated Resistance Spot Welder Low Power Consumption
Model CK-Q CK-W CK-E
Input Voltage/Frequency 1~380V 50/60Hz
rated input capacity 14KVA 16KVA 35KVA
Electrode arm length 330mm 380mm 380mm
Welding plate thickness ≤2+2 ≤2.5+2.5 ≤3+3
Welding rod diameter ≤φ3+φ3 ≤φ4+φ4 ≤φ5+φ5
Duty cycle 35% 35% 35%
Weight 100kg 138kg 160kg
