Product Details:
Payment & Shipping Terms:
|
| Product Name: | Galvanized Diamond Chain Fence Production Machine | Warranty: | 1 Year |
|---|---|---|---|
| Color: | Customer's Requirment | After Sales: | Engineers Available To Service Overseas |
| Wire Dia: | 1.5-4.5MM | Voltage: | 380V/50HZ |
| High Light: | chain link fence making machine,chain link weaving machine |
||
Automatic Galvanized Diamond Chain Fence Production Machine For Garden Farm Prison
presentation
Chain link machine for machine for manufacturing chain link fences of different sizes. The wire is taken in from the payoff stand and passed through the dies where the DIAMOND SIZE takes place. Different gap sizes. After passing from the die the diamond pattern wire is automatically thrown on the winding shaft in the stitching process. Once the stitching is complete the woven is manually glided down to enable the next stitch to take place.
Features
1. small size and fast speed.
2. high productivity;
3 .low noise;
4. low cost.
5. the machine is easy to operate and control.
6. reliable performance, little mechanical failure and convenient maintenance.
parameters
|
Name
|
Double wire chain link fence machine
|
|
Wire Dia.
|
1.5mm-4.5mm
|
|
Mesh size
|
25*25mm-150*150mm
|
|
Mesh width
|
0.5-4.0m
|
|
Capacity
|
25-150m2/h
|
|
Voltage
|
380V/50HZ(customized)
|
|
Name
|
Single wire chain link fence machine
|
|
Wire Dia.
|
1.5-4.5mm
|
|
Mesh size
|
25*25mm-150*150mm
|
|
Mesh width
|
0.5-4.0m
|
|
Capacity
|
30-180m2/h
|
|
Voltage
|
380V/50HZ(customized)
|
|
Name
|
Semi automatic chain link fence machine
|
|
Wire Dia.
|
1.5-4.5mm
|
|
Mesh size
|
25*25mm-100*100mm
|
|
Mesh width
|
0.5-4.0m
|
|
Capactity
|
20-80m2/h
|
|
Voltage
|
380V/50HZ(customized)
|
Usage
Chain Link Fence are widely use in animal husbandry, sports place, road greening defense, highway barrier, airport, port, residence, etc.
