High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving

I'm Online Chat Now

High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving

China High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving supplier
High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving supplier High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving supplier High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving supplier High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving supplier

Large Image :  High Efficiency Reinforcing Mesh Machine , Steel Bar Mesh Welding Machine Energy Saving

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-RM-2500Q

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: plastic warps
Delivery Time: 15 Workdays
Payment Terms: T/T, L/C, Western Union
Supply Ability: 25 Sets/Month
Contact Now
Detailed Product Description
Product Name: Automatic Coal Mine Reinforcing Mesh Production Welding Machine Width: Max 2.5m As Required
Wire Diameter: 5-12mm Voltage: 380V
After-sales: Engineers Available To Service Machinery Overseas Aperture: 100-300
High Light:

automatic wire mesh welding machine

,

reinforced mesh welding machine

Automatic Coal Mine Reinforcing Mesh Production Welding Machine


description

Reinforcing mesh is widely used in mine lane, wells, construction of tunnel support, protection and reinforced with a net, welded using a dedicated JIAKE welding mesh machines.
.
Features

1. Easy to operate: to finish one panel mesh, only need to turn on one auto-running button.

2. unique design of the cross wire input hopper: the machine will stop if there are no wires or abnormal happens, and it will run, when everything is OK.
3. welding stop function: when the wire welding, the main motor will stop temporarily, will continue to run after welding, insure the welding quality.
4. main motor servo control: with Delta VE high-end frequency concerter and PG card to make the main motor 0-1500r/min increase or decrease speed is 0.02s, zero speed, could 200% torque run, ensure the quick reaction of the machine.(motor with Omron encoder)
5. helical gear reducer: to ensure the machines high load run, and outside installation, easy for maintenance.
6. mesh output device: with Panasonic servo motor and planetary gear, ensure the system stability and end products precision.
7. automatic back to zero: the machine finished products, the mesh output device will automatically back to zero.
8. automatic turn on: with line wire input device, after finishing send the line wires, the machine will automatically turn on the machine.
9. failure display: when the machine fail, it will show on the touch screen(HMI) in english, very easy to maintain.
10. parameter set: all the parameter could be set on the touch screen in English.
11. all the spare parts are from famous brand at home and abroad.


Specification


1. Model:CK-FM-2500Q

wire diameter:3-6mm

mesh width: max 2.5m

mesh length: as required panel or roll mesh

wire spacing:50-200mm adjustable

 2. Model:CK-FM-2500W

wire diameter:4-8mm

mesh width: max 2.5m

mesh length: as required, panel mesh

wire spacing:100-300mm

3. Model:CK-RM-2500Q

wire diameter:5-12mm

mesh width:2.5m or as required

mesh length: as required

wire spacing:100-300mm


Packaging Details

1. The main body of the wire mesh welding machine will be packaged with plastic.
2. The anther parts of the wire mesh welding machine,will be packaged with cartons,they will be protected well.
3. If you have another package requirements,we will change it .
4. We will supply the best package for you.
