Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise

I'm Online Chat Now

Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise

China Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise supplier
Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise supplier Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise supplier Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise supplier Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise supplier

Large Image :  Hydraulic Pressure Steel Bar Mesh Welding Machine For 5 - 12 Mm , Low Noise

Product Details:

Place of Origin: Anping Hebei
Brand Name: Chengke
Certification: ISO
Model Number: CK-RM-2500

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: no
Delivery Time: 15 work days
Payment Terms: L/C, T/T
Supply Ability: 15
Contact Now
Detailed Product Description
Product Name: Hydraulic Pressure Steel Bar Welded Mesh Machine For 5 - 12 Mm Warranty: 1 Year
Voltage: 380v After-sales: Engineers Available To Service Machinery Overseas
Condition: New Wire Diameter: 5-12mm





Hydraulic Pressure Steel Bar Welded Mesh Machine For 5 - 12 mm





Specification



Automatic Building Concrete Rebar Mesh Welding Machine Electrodes Water Cooling
Item CK-RM-2500 CK-RM-2900 CK-RM-3300
Number of Electrodes 24 28 32
Max. Mesh Width 2500mm 2900mm 3300mm
Wire Diameter 3-8mm&5-12mm 5-12mm 5-12mm
Mesh Length 2-12m 2-12m 2-12m
Cross Wire Space ≥50mm ≥50mm ≥50mm
Line Wire Space 100-200mm 100-200mm 100-200mm
Electric Capacity ≥315KVA ≥315KVA ≥315KVA
Welding Speed 80t/min 80t/min 80t/min
Control System PLC Control PLC Control PLC Control
Special specification is available according to your requirements.





description



This machine has multi spot welding function, advanced control system enables the machine to weld the mesh in any sequence or any way. Using high quality air cylinder to provide welding force, the output is much more stable and durable than conventional mechanical type welding machines.Also machine features can be made by your idea together with our engineer technique support.Varies materials can be welded: weld mild steel wire, stainless wire, galvanized steel wire.Mesh panels: weld construction mesh panel, fridge shelf panel, shelf rack mesh panel, reinforcing mesh panelsMesh production line: producing rolled mesh in varies size.All kinds of mesh products: weld cage for bird, pet cage welding, mesh trolley welding, weld wire mesh basket, wire tray, fridge condensers, cable tray mesh etc.



Features


1. Easy to operate: to finish one panel mesh, only need to turn on one auto-running button.

2. unique design of the cross wire input hopper: the machine will stop if there are no wires or abnormal happens, and it will run, when everything is OK.
3. welding stop function: when the wire welding, the main motor will stop temporarily, will continue to run after welding, insure the welding quality.
4. main motor servo control: with Delta VE high-end frequency concerter and PG card to make the main motor 0-1500r/min increase or decrease speed is 0.02s, zero speed, could 200% torque run, ensure the quick reaction of the machine.(motor with Omron encoder)
5. helical gear reducer: to ensure the machines high load run, and outside installation, easy for maintenance.
6. mesh output device: with Panasonic servo motor and planetary gear, ensure the system stability and end products precision.
7. automatic back to zero: the machine finished products, the mesh output device will automatically back to zero.
8. automatic turn on: with line wire input device, after finishing send the line wires, the machine will automatically turn on the machine.
9. failure display: when the machine fail, it will show on the touch screen(HMI) in english, very easy to maintain.
10. parameter set: all the parameter could be set on the touch screen in English.
11. all the spare parts are from famous brand at home and abroad.



Usage



Water conservancy project, housing construction (floor plate, wall panel), bridge construction, highway construction, airport construction, railway construction, mine protection, which can be widely applied in construction industry.Fence netting (highway, rail road, mountain surrounding and stadium), fence mesh and the production of other protective fences.The production of bird cage, dog cage, various kinds of pet cages and all kinds of breeding cagesThe production of metal furniture, goods shelf, shopping cart and protective cover
