Product Details:
Payment & Shipping Terms:
|
| Product Name: | Automatic Wire Mesh Welding Machine | Welding Aperture: | 50x50-200x200mm |
|---|---|---|---|
| Voltage: | 380V | Speed: | 60 (times/minute) |
| Warranty: | 1 Year | After-sales: | Overseas Service Provided |
| High Light: | rebar mesh welding machine,automatic wire mesh machine |
||
Automatic Wire Mesh Welding Machine Easy To Learn And Operate
description
automatic wire mesh welding machine is complete equipment for welding wire mesh, which is manufactured by AWM based on learning foreign advanced experiences and advanced technologies in addition to actual production demands in the international market. It has many favorable features, such as high output, high precision, easy modification, low operation failure rate, strong capability in energy saving, low consumption, and high quality.
Application
1. Reasonable design, mature technology, simple operation, wide range of applications.
2 original products are used big brands, customers are easy to buy replacement.
3. Can be made according to the needs of users, follow-up processing easier, faster production.
4. Using rack and pinion drive, transmission efficiency.
5. splash small, low burn marks, improve the appearance of the net panel.
Specification
| Wire Diameter | 3-5mm |
| Longitude Wire Space | 50-200mm |
| Cross Wire Space | 50-200mm |
| Width of Mesh | Max2500mm |
| Welding Electrodes | 48pcs |
| Welding Speed | 45times/min |
| Longitude Wire Feeding | From Wire Coils |
| Cross Wire Feeding | Pre-cut&Straightened |
| Rated Electrical Power | 100kva*6pcs |
| The Wire Mesh Welding Machine is also able to be made to order according to customer’s requiremen | |
Usage
Automatic Wire Mesh Welding Machine is mainly used for welding wire mesh fence, including three-fold bending fence, double fence, bilateral wire fence, climbing network, etc., mainly for roads, railways, airports, residential, factory partition and so on Wai network.
