Product Details:
Payment & Shipping Terms:
|
| Product Name: | Automatic Reinforced Wire Drawing Machine | Max. Diameter Of Inlet Wire: | 13.5 Mm |
|---|---|---|---|
| Speed: | 0-90 M/min | Warranty: | 1 Year |
| After-sales: | Overseas Service Provided | Specifications Of Rolling: | 4-11 Mm |
| High Light: | stainless steel wire drawing machine,metal drawing machine |
||
Automatic Reinforced Wire Drawing Machine For Ribbed Steel Bar / Cold Drawn Spiral
description
1. This machine structure is compact, cover a small area, only need 30% of general equipment installation site.
2. Adopt international reducer, large torque, low noise, strong and durable.
3. Coiling block using carbide coating and wear resistant materials.
4. Adopts advanced frequency conversion and electromagnetic technology, and can save electricity by 40%, linear velocity can reach 0-90 m, improve production efficiency. Better protection of power transmission and transformation system and electrical equipment is not damaged, can greatly prolong the service life of the machine.
5. Mill box use NO. 45 pure steel casting, never cracking. Mill turbine sets a whole structure, with NO. 45 pure steel casting, large tension, wear-resisting, durable.
6. The producation process can one time finish and only need 1 to 2 person to operate.
7. The production process: Wire rod inspection-put wire-phosphorus removal-dry powder lubrication-not reduce the wire diameter(first time reduce, second ime reduce or third time reduce )-the finished product
Features
By the main reducer, mould box, wheel frame, a wire frame and electrical control system and so on each drawing drum by motor through a gear coupling transmission level 2 different cylindrical gear reduction ratio, so that the drum rotating work, drawing drum for vertical, installed on the cover of housing, gear pair USES dip oil lubrication of drum wall equipment cooling water spray device, to reduce after drawing wire residual heat on the surface of the drum, die immersed in water, to reduce the working temperature of the mold
parameters
| max. diameter of inlet wire | 13.5mm |
| Specifications of rolling | 4-11mm |
| speed of rolling | 0-90m/min |
| total installed capacity | 45-55Kw |
| length of the installation | 12m |
| speed dajustment mode | frequency control of motor speed |
