Product Details:
Payment & Shipping Terms:
|
| Product Name: | Poultry Wire Mesh Making Machine | Wire Diameter: | 1.8-2.5mm |
|---|---|---|---|
| Warranty: | 1 Year | After-sales: | Engineers Available To Service Machinery Overseas |
| Galvanized Mesh Poultry Cage Welding Machine: | 50-200mm | Voltage: | 380V |
| High Light: | chicken mesh making machine,wire cage welding machine |
||
Poultry Wire Mesh Making Machine / Making Breeding Chicken Cage Welding Machine
description
1 . The machine is used for fence 1.8- 3 mm , and it is an automatic equipment designed and manufactured by ourselves absorbing advanced resistance welding technology from home and abroad .
2 . The machine uses electrical and electronics synchronous control technique , welding time and separate welding adopt digital and integrated electric circuit .
3 . Air pressure control cross wire automatic falling one by one .
4 . Welding pressure are provided by pneumatic pressure system , uniform pressure and stable performance .
5 . The air cylinder controls the rod for pulling the mesh , which is easy to regulate mesh hole and mesh opening size is rather accurate , welding aperture could adjust randomly with certain range .
Features
1. Business model:factory direct sale
2 .Professional manufacture
3. No environment pollution
4. Smooth and beautiful welding spots
5. Product quality assurance
6. Available to weld multiple work pieces and heads in high efficiency
7. With credibility and protection
8. Good after sale service
Usage
Breed aquatic mesh ( poultry mesh , pigeon mesh, rabbit mesh , fox mesh and so on )
Building mesh ( reinforcing construction mesh , floor warning mesh , seed-bed mesh and room mesh )
Packing
1 . The spare parts and control cabinet will be loaded in wooden box.
2 . The main machine is nude packing or plastic packing
Specification
| Mechanical Steel Wire Chicken Cage Welding Machine High - Speed Stability | ||
| Model | CK-AC-1 | CK-AC-2 |
| Input power | 380V 50 Hz | 380V 50 Hz |
| Max. width | 1200mm | 1200mm |
| Line wire space | 25—200mm | 25—200mm |
| Cross wire space | 25—200mm | 25—200mm |
| Line wire diameter | 1.8-3.0mm | 1.8-3.0mm |
| Cross wire diameter | 1.8-2.5mm | 1.8-2.5mm |
| Rated capacity | 60kva*2 | 60kva*2 |
| Welding point No. | 16 | 16 |
| Motor power | 2.2kw | 2.2kw |
| Feed line wire | Coils wire | Coils wire |
| Feed cross wire | Coil wire | Coils wire & pre-cut wire |
| Welding speed | 40-50times/min | 50-60times/min |
Service
Pre-Sales Service:
Inquiry and consulting support.
Sample testing support.
View our Factory.
Online visit
After-Sales Service:
Training how to install,operate and maintain the machine.
Engineers available to service machinery overseas.
One year gurantee for the whole machine.
Operation manual is availabl
Sincerely look forward to cooperate with you ! For more details about wire mesh welding machine, welcome to contact with us in any time ! We will fully committed to provide the best quality products and services.
