Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine

I'm Online Chat Now

Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine

China Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine supplier
Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine supplier Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine supplier Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine supplier Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine supplier

Large Image :  Resistance Automatic Wire Mesh Welding Machine , Low Carbon Steel Wire Welded Wire Mesh Machine

Product Details:

Place of Origin: Heibei China
Brand Name: Chengke
Certification: ISO
Model Number: CK-RM-1500A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: No
Delivery Time: 15 Workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets/Month
Contact Now
Detailed Product Description
Product Name: Electric Welded Mesh Machines Voltage: 220V/380V/415V/440V
Color: Customer's Requirment Mesh Type: Roll Mesh
Power Needed: 80KW Material: Galvanized Wire/stainless Steel Wire/black Wire
High Light:

wire mesh roll welding machine

,

wire mesh making machine

Resistance Welded Wire Mesh Machine / Welded wire mesh production line





description



Welded wire mesh is made of high quality low carbon steel wire line of welding and become, then cold (plating) hot dip plating such as PVC plastic coated surface passivation plasticizing treatment to achieve smooth surface mesh uniform solder joints strong local stable machining performance good weatherability good anticorrosive property



Features



1. This machine is fully automatic to feed wires, weld mesh, cut edge and roll mesh.

2. The raw material is applicable for low-carbon steel wire, galvanizing wire and stainless steel wire.

3. It has advantages of reasonable design, low noise, stable working, easier operation etc.

4. The mesh size is precise and can be set according to customers’ requirements.

5. It adopts sealed &water cooling welding transformers, the scoria can not easily goes in.



After-sales



1. Guarantee time: 1 year since machine was installed at your factory but within 18 months against B/L date.
2. Within guarantee time, if any components are broken under normal condition, we can change for free.
3. We can send our best technician to buyer’s factory for installation, debugging and training.
4. Complete installation instructions, circuit diagram, manual operations and machine layout.
5. Timely reply for your machine questions.



Specification



                       Automatic Galvanized Steel Wire Roll Mesh Welding Machine
Model CK-RM-Q CK-RM-W CK-RM-E
Wire diameter 0.4-0.65mm 0.65-1.2/1.8mm 1.0-2.2mm
Aperture/pitch 1/4”-1/2” 1/2”-4” 1”-4”
Mesh width 3 feet, 4feet 4 feet, 5 fee 4 feet, 5 feet, 6 feet, 7feet
Motor 2.2kw 2.2kw 2.2kw;4.0kw
Welding speed Max. 75 rows/min Max. 120 rows/min Max. 80 rows/min
Measurement 2.3*1.4*1.5m 2.5/2.9*1.4*1.5m 2.5/2.9*1.4*1.5m
Weight 1.5T 2T, 2.5T 2T, 2.5T, 3T, 3.5T
Transformers 50kva*3 60kva*4;60kva*5 60kva*4/5/6/7
